- FQL450A+BS4522N Automatic L Type Sealer and shrink tunnel
- 【Brief】:This automatic shrink packaging machine is our new type machines, shrink packaging for food, beverages, candy, stationery, arts and crafts, hardware tools, daily necessities, chemical supplies and other objects. Shrinking machine packaging items can be sealed, moisture, pollution prevention, and protection of goods from the impact from the external buffer, especially when packing fragile items, to prevent the vessel broken when flying. In addition, you can reduce product demolished, the possibility of theft.
- 【Series】:L-type sealer and Shrink tunnel
- Description
-
Products Feature:
This automatic shrink packaging machine is our new type machines, shrink packaging for food, beverages, candy, stationery, arts and crafts, hardware tools, daily necessities, chemical supplies and other objects. Shrinking machine packaging items can be sealed, moisture, pollution prevention, and protection of goods from the impact from the external buffer, especially when packing fragile items, to prevent the vessel broken when flying. In addition, you can reduce product demolished, the possibility of theft.
All the heating tubes are made of stainless steel, highly efficient energy-saving (saving more than 15%) and contraction temperature and motor transfer speed is adjusted, and a wide adjustment range, and the original drum rotation device can work continuously. Can adjust its sealing and cutting the bottom of the shrinking machine is equipped with casters can be free to promote any adjustment of the level, according to the size of the packaging.
Technician Specification
Model
FQL-450A
FQL-550A
Power supply
220v 50/60HZ
Power
1.35KW
1.5KW
The highest packing
125mm
125mm
The size of the sealing line
560x440mm
660x540mm
Production capacity
15-30bags/min
Atmospheric pressure
0.5Mpa
Dimensions
1550x730x1360mm
1650x830x1360mm
The whole weight
300kgs
350kgs
Model
BS4522N
BS5522N
Voltage
380V/50HZ, 3P
Power
12KW
12KW
Loading weight
30kgs
30kgs
Tunnel Size (mm)
1200×450×220
1200×550×220
Dimension
1700×720×1300
1700×820×1300
Conveyor speed
0-10m/min
Weight
130kgs
150kgs
